Recently, our Dynamics 365 for Finance and Operations (D365FO) team went through a tenant migration. With it, came the process of reconnecting all the points of integration for our internal environments. Unfortunately we hit a snag with the “Unable to communicate with the SharePoint server” error. Here is how we were able to resolve this issue.

Connecting D365FO with SharePoint

Following the Microsoft documentation, we proceeded to Organization Administration → Document Management → Document Management Parameters. We then selected the SharePoint tab.

configure SharePoint storage options

We then entered in our SharePoint site and clicked “Test SharePoint connection.” We received this message “Unable to communicate with the SharePoint server: sikichd365.sharepoint.com.”

"Unable to communicate with the SharePoint server" error

Fortunately, this is a cloud hosted environment that allows access to this virtual machine. Once we opened the virtual machine, the first step was to look at Event Viewer, since this was trying to call an API for a SharePoint Connection.

Within Event Viewer, we navigated to Applications and Services Logs → Microsoft → Dynamics → AX-DocumentManagement and viewed the Operational Logs.

Event Viewer

The logs provided all the same details: “Could not load file or assembly ‘Microsoft.IdentityModel.Extensions, Version=2.0.0.0, Culture=neutral, PublicKeyToken=69c3241e6f0468ca’ or one of its dependencies. The system cannot find the file specified.”

error message

What does Microsoft.IdentityModel file do? This file allows for Dynamics (or other programs) to connect with SharePoint. Specifically, it is where OAuth and S2SAuthentication are stored. Without this file, Dynamics cannot connect to SharePoint.

After some searching through folder C:\Windows\Microsoft.NET\assembly\GAC_MSIL, we discovered that Microsoft.IdentityModel.Extensions does not exist anymore within the file structure.

missing file

Through more searching, we learned that Microsoft changed the file structure. Microsoft.IdentityModel is structured in Windows Identity Foundation (WIF). Microsoft integrated Windows Identity Foundation into .NET 4.5. In doing so, they moved the majority of Microsoft.IdentityModel to System.Security, System.ServiceModel.Security, and System.IdentityModel.

One item that was left out was IdentityModel.Extensions, which was the reason for the Event Viewer error message.

Resolution

There are a couple of ways we can get this file into our environment.

  • Direct Download and Install.
  • Install Office Developer Tools via Visual Studio.

We took option one, a Direct Download and Install. Since this environment was not going to be used for development, installing the Office Developer Tools was more work than required for the task.

From the Microsoft Downloads site, we downloaded the MSI file. You can use a tool such as 7zip to view its archive and see it contains our missing dll file.

Microsoft Downloads

We moved the MSI file to the virtual machine and installed it following through the prompts and install Microsoft Identity Extensions.

Microsoft Identify Extensions setup

After the install, we navigated back to confirm the file was there.

file confirmation

After the install was complete and the file confirmed to be in its correct location, we restarted the World Wide Web Publishing Service on the virtual machine. This will restart IIS and apply the changes. Give the restart a couple of minutes to fully take effect.

World Wide Web Publishing Service

We then refreshed our Dynamics instance and tested the SharePoint connection once more. The connection was successful!

successful test

If you have any questions on how to resolve the “Unable to communicate with the SharePoint server” error when connecting SharePoint with D365FO, or any other question about SharePoint and D365FO, please contact us at any time!
